Description
The APC-R Mini Lite is the wired version of the APC-R Mini: same controller, same DJI RS compatibility, same Middle Control workflow, €100 less. It has no Wi-Fi, Bluetooth or tally light, which makes it a good fit for rigs that already run Ethernet to every camera, and for permanent installations.
What it does
Mount and go — fits on the gimbal’s RSA port; power and data go through that one connection. No adapter, no battery.
Wired Ethernet — one cable per gimbal, for the lowest latency and best reliability.
Position presets — save pan, tilt, roll and zoom together with iris, ISO, white balance and ND, then recall them from a Stream Deck button or a joystick button.
Up to 15 gimbals from one computer running Middle Control, one Lite per gimbal.
Mini or Mini Lite?
The Lite has no Wi-Fi, no Bluetooth and no tally light, and these can’t be added later. The Mini uses Bluetooth for wireless Blackmagic camera control; with the Lite, Blackmagic cameras are controlled through an ATEM over SDI/HDMI or directly over Ethernet by Middle Control. If you need wireless operation or a tally on the unit, choose the APC-R Mini.
Control and compatibility
A USB gaming joystick, the Middle Remote, a Stream Deck with Companion, VISCA over IP (Middle Control Pro), a Blackmagic ATEM Advanced Panel, or your own TCP commands through the SDK. They all work through Middle Control, which is free on macOS and in public beta on Windows. Works with DJI RS2, RS2 Pro, RS3 Pro, RS4, RS4 Pro and RS5. Gimbals without an RSA port (RSC2, RS3, RS3 Mini, RS4 Mini) are not supported. See the compatibility page for your setup.
connectivity
Ethernet, USB-C (power, setup & updates)
warranty
Limited 1-Year Manufacturer Warranty
input voltage
Direct from the gimbal's RSA port, or 5V DC via USB-C
power consumption
~1W
product weight
0.12lbs / 54g
product dimensions
Length : 9.5cm / Width : 3.2cm / Height : 2.4cm
storage temperature
14 to 140°F / -10 to 60°C
other specifications
Mounts on the DJI RSA port (CANBUS) · wired Ethernet only, no radio · up to 15 units per computer · EAN 3770018577470
package weight
0.14lbs / 70g
box dimensions
(LxWxH) : 4cm x 4cm x 11cm | 7.1”x4.7”x2.4”
1x APC-R Mini Lite
⚠️ Prior to purchase, please read the compatibility section carefully, to make sure you have the proper camera, switcher, gimbal and to see which settings you can control.
Shipments are shipped through DHL Express from our warehouse in Europe.
For customers in the USA, all customs, duties, and taxes are now included in your purchase price — no extra fees at delivery!
Other international orders may be subject to customs duties, taxes, and fees required for the shipment's entry into the destination country. Customs, duties and taxes vary from country to country and are out of our control. Import taxes are not included in the cost of shipping or handling your order.
We offer a 30 Day Money Back Guarantee. If you are not fully satisfied with the product, then let us know within 30 calendar days, and we will give you return instructions and a full refund of the money paid once received (you only have to pay for return shipping fees).
