APC-R Mini
€449 EUR €449 EUR
Tax excluded. Additional VAT applies to EU customers.
Order now, ships 15 November Back in stock soon. Orders ship in the order they were placed, so ordering now reserves yours.
Description

The APC-R Mini mounts on the RSA port of a DJI RS gimbal and turns it into a PTZ head you control over the network. Power and data both go through that port: no adapter, no battery, no extra cable. You need one Mini per gimbal, and one computer running Middle Control can drive up to 15 of them.

What it does

  • Ethernet or Wi-Fi — use Ethernet for the lowest latency and best reliability, or 2.4 GHz Wi-Fi for small venues and studios. If the cable gets unplugged, it switches to Wi-Fi within 5 to 15 seconds.
  • Built-in tally — red on Program, green on Preview. Brightness is adjustable in Middle Control or on the unit.
  • Position presets — save pan, tilt, roll and zoom together with iris, ISO, white balance and ND, then recall them from a Stream Deck button or a joystick button.
  • Wireless Blackmagic control — pair it with a Blackmagic camera over Bluetooth to adjust shutter, iris, white balance, gain and focus, plus the ATEM colour controls (lift, gamma, saturation, sharpening) through Middle Control.

Six ways to control it

A USB gaming joystick, the Middle Remote, a Stream Deck with Companion, VISCA over IP (Middle Control Pro), a Blackmagic ATEM Advanced Panel, or your own TCP commands through the SDK. They all work through Middle Control, which is free on macOS and in public beta on Windows. You set the unit up from your phone with the free Middle Setup app (iOS and Android).

Compatibility

Works with the current DJI RS line: RS2, RS2 Pro, RS3 Pro, RS4, RS4 Pro and RS5. Gimbals without an RSA port (RSC2, RS3, RS3 Mini, RS4 Mini) are not supported. For cameras and switchers, see the compatibility page.

The Mini has the same electronics as the APC-R and gets the same updates, in a 54 g unit that replaces the APC-R, the Gimbal Adapter and the Middle Tally. If you only need wired Ethernet, the APC-R Mini Lite drops Wi-Fi, Bluetooth and the tally light and costs €100 less.
  • connectivity
    Ethernet, 2.4 GHz Wi-Fi, Bluetooth (Blackmagic cameras), USB-C (power, setup & updates)
  • warranty
    Limited 1-Year Manufacturer Warranty
  • input voltage
    Direct from the gimbal's RSA port, or 5V DC via USB-C
  • power consumption
    ~1W
  • product weight
    0.12lbs / 54g
  • product dimensions
    Length : 9.5cm / Width : 3.2cm / Height : 2.4cm
  • storage temperature
    14 to 140°F / -10 to 60°C
  • other specifications
    Mounts on the DJI RSA port (CANBUS) · built-in red / green tally · up to 15 units per computer · Middle Setup app for iOS and Android · EAN 3770018577463
  • package weight
    0.15lbs / 80g
  • box dimensions
    (LxWxH) : 4cm x 4cm x 11cm | 7.1”x4.7”x2.4”
  • 1x APC-R Mini

⚠️ Prior to purchase, please read the compatibility section carefully, to make sure you have the proper camera, switcher, gimbal and to see which settings you can control.

Shipments are shipped through DHL Express from our warehouse in Europe.

For customers in the USA, all customs, duties, and taxes are now included in your purchase price — no extra fees at delivery!


Other international orders may be subject to customs duties, taxes, and fees required for the shipment's entry into the destination country. Customs, duties and taxes vary from country to country and are out of our control. Import taxes are not included in the cost of shipping or handling your order.

We offer a 30 Day Money Back Guarantee.  If you are not fully satisfied with the product, then let us know within 30 calendar days, and we will give you return instructions and a full refund of the money paid once received (you only have to pay for return shipping fees).
